产品详情
技术细节 |
-X横轴行程:460[mm] |
-X轴快速进给速度:10[m/min] |
-X轴分辨率:0.0001[°] |
-垂直轴Y行程:190[mm] |
-Y轴快速进给速度:6[m/min] |
-Y轴分辨率:0.0001[°] |
-Z轴行程:730[mm] |
-Z轴快速进给速度:6[m/min] |
-Z轴分辨率:0.0001[°] |
-静止轴W1:730[mm] |
-轴w1快速进给速度:7.5[m/min] |
-Z轴分辨率:0.0001[°] |
-旋转轴B行程:+/-200[°] |
-B轴快速进给速度:21600[°/min] |
-B轴分辨率:0.0001[°] |
-轴C(分隔器):360[°] |
-C轴分辨率:0.0001[°] |
-附件锥度:ISO 50 |
主轴 |
-主轴功率:9[KW] |
TECHNICAL DETAILS |
- X transversal axis stroke : 460 [mm] |
- Axis X quick feed speed : 10 [m/min] |
- Axis X resolution : 0.0001 [°] |
- Vertical axis Y stroke : 190 [mm] |
- Axis Y quick feed speeds : 6 [m/min] |
- Axis Y resolution : 0.0001 [°] |
- Axis Z stroke : 730 [mm] |
- Axis Z quick feed speeds : 6 [m/min] |
- Axis Z resolution : 0.0001 [°] |
- Rest axis W1 : 730 [mm] |
- Axis w1 quick feed speeds : 7.5 [m/min] |
- Axis Z resolution : 0.0001 [°] |
- Swiveling axis B stroke : +/- 200 [°] |
- Axis B quick feed speeds : 21600 [°/min] |
- Axis B resolution : 0.0001 [°] |
- Axis C (divider) : 360 [°] |
- Axis C resolution : 0.0001 [°] |
- Attachment taper : ISO 50 |
SPINDLE |
- Spindle power : 9 [KW] |
